集想法走上、出产地、发(fa)卖办(ban)事人
于集成的专注于黄金麻石材开发利用和手工加工系统紫装的国家级高新产业传统手工艺公司企业
| 称号 | Name | 单元/Unit | 2QYK-3600 |
2QYK-3300 |
2QYK-3600 |
2QYK-4000/4200 | 2QYK-5000 |
| 范例 | Type | A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
A/B/C/D |
|
| 锯片直径 | Blade diameter |
mm |
Φ3000 | Φ3300 | Φ3600 |
Φ4000/Φ4200 |
Φ5000 |
| 最大切割深度 | Max.cutting depth |
mm |
1250 | 1400 | 1500 | 1750/1850 | 2250 |
|
主机设备瓦数 |
Power ofmain motor |
kw | 55x2 | 55x2 | 55x2 | 65X2 | 65X2 |
|
油阀电气电机功率 |
Power of pump motor |
kw |
3.5 | 3.5 | 3.5 | 4 | 4 |
| 路程机电功率 |
Power of stroke motor |
kw |
2.2 | 2.2 | 2.2 | 3 | 4 |
| 纵向换轨机电功率 |
|
kw |
0.75x2 | 0.75x2 | 0.75x2 | 1.1X2 | 1.1X2 |
|
元器件效率 |
Gross power |
kw |
117.2 | 117.2 | 117.2 | 139.2 | 140.2 |
|
造型面积 |
Dimensions(LxWxH) |
mm | 3200x2100x2800 | 3500x2200x3200 | 3800x2200x3100 | 420X2100X3500 | 5200X2200X4200 |
|
元器件使用 |
Gross weight |
kg | 7000-8500 | 7000-8500 | 7500-10000 | 9500-11500 | 9500-12500 |
| 切割宽度 | Cutting width of TypeA |
mm |
1360-1900 | 1360-1900 | 1360-1900 | 1950-2450 | 2000-2500 |
|
|
TypeB |
mm |
1800-2300 | 1800-2300 | 1900-2400 | 2400-2900 | 2400-2900 |
|
|
TypeC |
mm |
2200-2700 | 2200-2700 |
2300-2800 |
2800-3300 | 2800-3300 |
|
|
TypeD |
mm |
2700-3200 |
2700-3200 |
2700-3200 | 3200-3700 | 3200-3700 |
| 一米四机台 |
|
|
|
|
|
|
|
|
零件及运转情况信噪比 |
Gross weight |
kg |
7000 | 7500 | 7800 | / | / |
| 的形状的尺寸 | Dimensions(LxWxH) |
mm |
3200z1500z2630 |
3500x1500x2880 |
3700x1500x3050 |
/ | / |
|
打孔横向 |
Cutting width |
mm |
1380-1880 | 1380-1880 | 1380-1880 | / | / |
| 四驱机型 |
|
|
|
|
|
|
|
| 纵横驱动机电功率 |
|
kw | 1.5x2 | 1.5x2 | 1.5x2 | 1.5X2 | 1.5X2 |
| 总功率 |
Gross power |
kw | 116.5 | 116.5 | 116.5 | 137 | 137 |
